Schaffer Diaphragm Pressure Gauge

Get a Price/Quote

MOQ : 100 Pieces

Schaffer Diaphragm Pressure Gauge Specification

Thread
1/2 BSP/NPT

Sensor Type
Diaphragm Sensing Element

Grade
Industrial/Commercial

Outer Size
110 mm

Display
Analog Dial

Bourdon Tube
Not Applicable (Diaphragm Type)

Seal Material
PTFE / Neoprene / Viton

Material
Stainless Steel / Mild Steel

Dial Material
Aluminium (White Printed Black)

Pointer Material
Black Anodized Aluminium

Processing Type
Machined & Assembled

Diameter
100 mm

Glass Size
Customized/Standard

Mount Type
Bottom/Back Flange

Scale Range
0-16 bar / Customized

Accuracy
1.6% F.S.

Finishing
Powder Coated/Polished

Measure Pressure Of
Gases, Liquids, Corrosive Media

Accessories
Mounting Bracket, Process Connection Fittings

Diaphragm Material
SS316 / Hastelloy / PTFE Lined

Operating Temperature Range
-20C to +60C

Movement
Brass/Bronze

Protection Class
IP 65

Window Material
Acrylic / Toughened Glass

Zero Adjustable
Yes

Application
Chemical, Petrochemical, Pharmaceutical, Water Treatment, Process Industries

Case Material
SS304 / SS316 / Mild Steel

Process Connection Position
Bottom/Back Entry

Schaffer Diaphragm Pressure Gauge Trade Information

Minimum Order Quantity
100 Pieces

Payment Terms
Cash in Advance (CID)

Supply Ability
5000 Pieces Per Month

Delivery Time
10 Days

Main Domestic Market
All India

About Schaffer Diaphragm Pressure Gauge

Introducing the new release Schaffer Diaphragm Pressure Gauge, the finest in precision pressure measurement-now available at clearance discount rates! Crafted with superlative materials including SS304/SS316/Mild Steel cases and Hastelloy or PTFE lined diaphragms, this champion gauge delivers superior accuracy (1.6% F.S.) and reliability. Designed for demanding industrial and commercial sectors like chemical, petrochemical, pharmaceutical, and water treatment, it features IP65 protection, adjustable zero, and a robust analog dial display. Includes mounting accessories for seamless installation. Secure this highest-quality solution from a leading Indian exporter, supplier, and trader today!

Advantages and Features of Schaffer Diaphragm Pressure Gauge

Benefit from unparalleled performance with the Schaffer Diaphragm Pressure Gauge, designed for the toughest environments. The use of high-quality SS316 and Hastelloy materials provides excellent corrosion resistance. Its versatile application extends to chemical, petrochemical, pharmaceutical, and water treatment industries, making it a preferred choice for both industrial and commercial sites. The robust construction, zero adjustability, and IP65 protection class ensure reliable operation and longevity, even under extreme conditions.

Export, Sale, and Delivery of Schaffer Diaphragm Pressure Gauge

The Schaffer Diaphragm Pressure Gauge is supplied to main export markets including Asia, Africa, and the Middle East. The sale price and charges are efficiently managed with FOB Port options spanning major Indian ports for hassle-free handover. Domestically, this product is readily available across India's leading industrial markets, ensuring prompt delivery and competitive pricing for both domestic and international buyers.

FAQ's of Schaffer Diaphragm Pressure Gauge:

Q: How does the Schaffer Diaphragm Pressure Gauge work in corrosive environments?

A: The gauge uses materials like SS316 and Hastelloy for the diaphragm and PTFE/Neoprene/Viton for seals, providing superior resistance to corrosive media, making it effective in chemical and petrochemical applications.

Q: What are the primary advantages of using this pressure gauge in industrial settings?

A: It offers high accuracy, adjustable zero point, rugged build, IP65 protection, and compatibility with corrosive and standard gases or liquids, ensuring dependable performance in diverse process industries.

Q: Where can the Schaffer Diaphragm Pressure Gauge be installed?

A: This gauge can be mounted via a bottom or back flange, making it suitable for a variety of installation setups in processes at chemical plants, water treatment facilities, and pharmaceutical industries.

Q: What is included with each purchase of this gauge?

A: Every unit comes with a mounting bracket, process connection fittings, and choice of powder coated or polished finish ensuring quick and secure installation.

Q: How does one adjust the zero setting on this pressure gauge?

A: The gauge features a zero adjustment screw, allowing users to recalibrate the pointer for precise measurement, ensuring maintained accuracy throughout its service life.
